DocumentFileDetailsServiceReturnModel Complex Type

Namespace

http://schemas.datacontract.org/2004/07/AlphaTrust.Pronto.ServiceContracts.Models.ServiceReturns

Diagram

Overview

DocumentFileDetailsServiceReturnModel

Sequence

IsSuccessful optional xs:boolean

Message optional xs:string

DocumentFiles optional ArrayOfDocumentFileDetailsModel Complex Type

Sequence

DocumentFileDetailsModel 0..∞ DocumentFileDetailsModel Complex Type

Sequence

DocumentID optional xs:int

File optional DocumentFileModel Complex Type

Sequence

FileBytes optional xs:base64Binary

FileName optional xs:string

MimeType optional xs:string

ProcessingTime optional xs:string

TimeZoneUtcOffset optional xs:double

Used By

GetDocumentFilesResult Element
GetPdfDataFilesResult Element
GetDocumentFilesInTiffFormatResult Element
DocumentFileDetailsServiceReturnModel Element

Source

<xs:complexType name="DocumentFileDetailsServiceReturnModel" xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:sequence>
    <xs:element minOccurs="0" name="IsSuccessful" type="xs:boolean" />
    <xs:element minOccurs="0" name="Message" nillable="true" type="xs:string" />
    <xs:element minOccurs="0" name="DocumentFiles" nillable="true" type="q18:ArrayOfDocumentFileDetailsModel" xmlns:q18="http://schemas.datacontract.org/2004/07/AlphaTrust.Pronto.ServiceContracts.Models.Document" />
    <xs:element minOccurs="0" name="ProcessingTime" nillable="true" type="xs:string" />
    <xs:element minOccurs="0" name="TimeZoneUtcOffset" type="xs:double" />
  </xs:sequence>
</xs:complexType>
