Transaction
TransactionUpdateModel Complex Type
Transaction : TransactionUpdateModel Complex Type
Namespace http://schemas.datacontract.org/2004/07/AlphaTrust.Pronto.ServiceContracts.Models.Transaction
Diagram
TSCleanup Element EmailTemplateSetLanguage Element IncludeUploadedAttachmentsInThirdPartyNotifications Element Placeholders Element Language Element EmailAddress Element FullName Element Sequence TransactionNotificationDetailsModel Element Sequence ThirdPartyNotifications Element EnableMessagePromptOnCancel Element SendExpiredNotification Element SendCancelledNotification Element SendCompletedNotification Element SessionExpirationMinutes Element EmailTemplateSetName Element ExpirationDate Element CreatorUserID Element StateProvince Element Country Element Rule Element Sequence Jurisdiction Element FooterContent Element FromEmailAddress Element FromName Element Sequence OutgoingEmailDetails Element string Element Sequence CompleteNotificationEmailAddresses Element DisableCompleteNotificationAttachments Element IsParticipantOrderNonSequential Element IsTest Element Description Element ProntoID Element ID Element Sequence TransactionUpdateModel Complex Type
Overview
TransactionUpdateModel
Sequence
ID optional xs:int
ProntoID optional xs:string
Description optional xs:string
IsTest optional xs:boolean
IsParticipantOrderNonSequential optional xs:boolean
DisableCompleteNotificationAttachments optional xs:boolean
CompleteNotificationEmailAddresses optional ArrayOfstring Complex Type
Sequence
string 0..∞ xs:string
OutgoingEmailDetails optional OutgoingEmailDetailsModel Complex Type
Sequence
FromName optional xs:string
FromEmailAddress optional xs:string
FooterContent optional xs:string
Jurisdiction optional JurisdictionModel Complex Type
Sequence
Rule optional xs:string
Country optional xs:string
StateProvince optional xs:string
CreatorUserID optional xs:int
ExpirationDate optional xs:dateTime
EmailTemplateSetName optional xs:string
SessionExpirationMinutes optional xs:short
SendCompletedNotification optional xs:boolean
SendCancelledNotification optional xs:boolean
SendExpiredNotification optional xs:boolean
EnableMessagePromptOnCancel optional xs:boolean
ThirdPartyNotifications optional ArrayOfTransactionNotificationDetailsModel Complex Type
IncludeUploadedAttachmentsInThirdPartyNotifications optional xs:boolean
EmailTemplateSetLanguage optional xs:string
TSCleanup optional xs:dateTime
Used By
TransactionUpdateModel Element
TransactionUpdateModel Element
Source
<xs:complexType name="TransactionUpdateModel" xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:sequence>
    <xs:element minOccurs="0" name="ID" type="xs:int" />
    <xs:element minOccurs="0" name="ProntoID" nillable="true" type="xs:string" />
    <xs:element minOccurs="0" name="Description" nillable="true" type="xs:string" />
    <xs:element minOccurs="0" name="IsTest" type="xs:boolean" />
    <xs:element minOccurs="0" name="IsParticipantOrderNonSequential" type="xs:boolean" />
    <xs:element minOccurs="0" name="DisableCompleteNotificationAttachments" type="xs:boolean" />
    <xs:element minOccurs="0" name="CompleteNotificationEmailAddresses" nillable="true" type="q23:ArrayOfstring" xmlns:q23="http://schemas.microsoft.com/2003/10/Serialization/Arrays" />
    <xs:element minOccurs="0" name="OutgoingEmailDetails" nillable="true" type="tns:OutgoingEmailDetailsModel" />
    <xs:element minOccurs="0" name="Jurisdiction" nillable="true" type="tns:JurisdictionModel" />
    <xs:element minOccurs="0" name="CreatorUserID" nillable="true" type="xs:int" />
    <xs:element minOccurs="0" name="ExpirationDate" nillable="true" type="xs:dateTime" />
    <xs:element minOccurs="0" name="EmailTemplateSetName" nillable="true" type="xs:string" />
    <xs:element minOccurs="0" name="SessionExpirationMinutes" nillable="true" type="xs:short" />
    <xs:element minOccurs="0" name="SendCompletedNotification" type="xs:boolean" />
    <xs:element minOccurs="0" name="SendCancelledNotification" type="xs:boolean" />
    <xs:element minOccurs="0" name="SendExpiredNotification" type="xs:boolean" />
    <xs:element minOccurs="0" name="EnableMessagePromptOnCancel" type="xs:boolean" />
    <xs:element minOccurs="0" name="ThirdPartyNotifications" nillable="true" type="tns:ArrayOfTransactionNotificationDetailsModel" />
    <xs:element minOccurs="0" name="IncludeUploadedAttachmentsInThirdPartyNotifications" type="xs:boolean" />
    <xs:element minOccurs="0" name="EmailTemplateSetLanguage" nillable="true" type="xs:string" />
    <xs:element minOccurs="0" name="TSCleanup" nillable="true" type="xs:dateTime" />
  </xs:sequence>
</xs:complexType>
